Máy Chủ FusionServer 2288H V6 – 25×2.5″
0₫
Máy Chủ FusionServer 2288H V6 – 25×2.5″
- Processor: 1x Intel Xeon Silver 4310
- Memory: 1x DDR4 RDIMM 32GB
- Hard Drive: 2x SSD 480GB SATA 2.5″
- Raid Controller: MR 9560-8i
- Network Controller: 10GE (CX-4 Lx) 2-Port SFP+, 4-Port 1Gb RJ45, 2 x Optical transceiver
- Power Supply: 2 x 900W platinum
- Form Factor: 2U rack server
Giá chưa bao gồm VAT
Mô tả
Thông Số Kỹ Thuật Máy Chủ FusionServer 2288H V6
| Model | FusionServer 2288H V6 |
| Form Factor | 2U rack server |
| Processors | One or two 3rd Gen Intel® Xeon® Scalable Ice Lake processors (8300/6300/5300/4300 series), TDP up to 270 W |
|
Chipset
|
Intel C621A |
| Memory | 16/32 DDR4 DIMMs, up to 3200 MT/s; 16 Optane™ PMem 200 series, up to 3200 MT/s |
| Local Storage | Supports various drive configurations and hot swappable:
• 8-31 x 2.5-inch SAS/SATA/SSD drives • 12-20 x 3.5-inch SAS/SATA drives • 4/8/16/24 NVMe SSDs • Supports a maximum of 45 x 2.5-inch drives or 34 full-NVMe SSDs Supports flash storage: • 2 x M.2 SSDs |
| RAID Support | Supports RAID 0, 1, 10, 5, 50, 6, or 60, optional supercapacitor for cache data power failure protection, RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration. |
| Network |
Provides expansion capability of multiple types of networks. Provides the OCP 3.0 network adapter. The two FlexIO card slots support two OCP 3.0 network adapters respectively, which can be configured as required. Hots wappable function supported |
| PCIe Expansion | Provides a maximum of fourteen PCIe 4.0 slots, including one PCIe slot dedicated for RAID controller card, two FlexIO card slots dedicated for OCP 3.0, and eleven PCIe 4.0 slots for standard PCIe cards. |
|
Fan Modules
|
Four hot-swappable counter-rotating fan modules in N+1 redundancy mode |
| Power Supply | • 900 W AC Platinum/Titanium PSUs (input: 100 V to 240 V AC, or 192 V to 288 V DC)
• 1500 W AC Platinum PSUs 1000 W (input: 100 V to 127 V AC) 1500 W (input: 200 V to 240 V AC, or 192 V to 288 V DC) • 1500 W 380 V HVDC PSUs (input: 260 V to 400 V DC) • 1200 W 1200 W –48 V to –60 V DC PSUs (input: –38.4 V to –72 V DC) • 3000 W AC Titanium PSUs 2500 W (input: 200 V to 220 V AC) 2900 W (input: 220 V to 230 V AC) 3000 W (input: 230 V to 240 V AC) • 2000 W AC Platinum PSUs 1800 W (input: 200 V to 220 V AC, or 192 V to 200 V DC) 2000 W (input: 220 V to 240 V AC, or 200 V to 288 V DC) |
Thông số kỹ thuật chi tiết xem tại đây
Quý khách vui lòng liên hệ với chúng tôi để hiểu thêm thông tin sản phẩm, báo giá, đặt hàng sản phẩm Máy chủ xFusion chính hãng:
Website: https://maychuvip.com
Hotline: 0867.111.333
Email: kinhdoanh@maychuviet.vn
