Card Lan HP NC523SFP 10G, 2 port 10Gbps SFP+ server adapter

Chi tiết
Đánh giá

Chi tiết

Mô tả Card Lan HP NC523SFP 10G, 2 port 10Gbps SFP+ server adapter

Sử dụng cho: Các dòng máy chủ server HP , Dell, IBM ...
Và các dòng máy để bàn bình thường khác

- Card Lan HP NC523SFP 10G, 2 port 10Gbps SFP+ server adapter
- Giao tiếp chuẩn PCI-E 8X, gắn được khe VGA (16X).
- Tương thích tốt mainboard thường và server.

Tình trạng: Hàng tháo máy server
Mới 95% , gần như mới
Bảo hành : 01 tháng
Bảo hành 06 tháng +10%, 12 tháng +20% giá sản phẩm

Feature	Description
Model number	593717-B21
Spare part number	593742-001
Kit contents	HP NC523SFP 10Gb 2-port server adapter Full height bracket (installed on card) Low-profile bracket Quick install card User documentation and driver download information Product warranty statement
Performance	Dual-port 10 Gigabit Ethernet throughput: 20,000 Mb/s full duplex Ethernet transfer rate per port (40 Gb/s aggregate full duplex) PCI express interface: Eight lane (x8) PCI Express bus based on the PCIe v2.0 standard. Backward compatible with four lane (x4) PCI Express. Automatically auto-sensing between x8 and x4 slots. Jumbo frames: 9,000 byte transmission unit (MTU) Supports 9KB jumbo frames SR-IOV: Supports industry standard SR-IOV (Single Root Input Output Virtualization) TCP stateless offloading: TCP/IP checksum offload (TCO) Large Send Offload (LSO) or TCP Segmentation Offload (TSO) Interrupt coalescing: Groups multiple packets, thereby reducing the number of interrupts sent to the host. 802.1p QoS tagging: Allows to mark or tag frames with a priority level across a QoS-aware network for improved traffic flow.
Network management	Management support: HP Systems Insight Manager or other management application that support SNMP. Server integration: Optimized for HP ProLiant servers. Provides users with a single point of contact for both their servers and their network adapters. LED indicators: Bracket LED indicators show link integrity and network activity for easy troubleshooting. PXE Support for pre-boot execution environment (PXE) enables automatic deployment of computing resources remotely from anywhere. It allows a new or existing server to boot over the network and download software, including the operating system, from a management/ deployment server at another location on the network. Additionally, PXE enables decentralized software distribution and remote troubleshooting and repairs.
Compatible servers 1	ProLiant DL (rack-optimized): HP ProLiant DL160 G6, HP ProLiant DL160 Gen8, HP ProLiant DL165 G7, HP ProLiant DL180 G6, HP ProLiant DL320 G6, HP ProLiant DL320e Gen8, HP ProLiant DL360 G6, HP ProLiant DL360 G7, HP ProLiant DL360e Gen8, HP ProLiant DL360p Gen8, HP ProLiant DL370 G6, HP ProLiant DL380 G7, HP ProLiant DL380e Gen8, HP ProLiant DL380p Gen8, HP ProLiant DL385 G7, HP ProLiant DL385p Gen8, HP ProLiant DL560 Gen8, HP ProLiant DL580 G7, HP ProLiant DL585 G6, HP ProLiant DL585 G7, HP ProLiant DL785 G6, HP ProLiant DL980 G7, ProLiant ML (expansion-optimized): HP ProLiant ML310e Gen8, HP ProLiant ML330 G6, HP ProLiant ML350 G6, HP ProLiant ML350e Gen8, HP ProLiant ML350p Gen8, HP ProLiant ML370 G6, ProLiant SL (scalable line): HP ProLiant SL160s G6, HP ProLiant SL160z G6, HP ProLiant SL165s G7, HP ProLiant SL165z G7, HP ProLiant SL170z G6, HP ProLiant SL2x170z G6, HP ProLiant SL230s Gen8, HP ProLiant SL250s Gen8, HP ProLiant SL270s Gen8
